The competition between cold shrink Cable sleeves and traditional heat shrink sleeves is essentially a revolutionary breakthrough in materials science and installation technology. The following reveals the disruptive advantages of cold shrink tubing from five dimensions:
1、 Materials Science: Elastic Memory vs. Plastic Curing
1. Cold shrink tubing
-Core material: Solid silicone rubber or ethylene propylene diene monomer (EPDM), with permanent elastic memory function.
-Breathing effect: It expands and contracts synchronously with the thermal expansion and contraction of the cable, completely solving the "cold and hot breathing gap" caused by the hardening of traditional heat shrink tubing (interface separation caused by the thermal expansion and contraction of the cable core during operation), and preventing moisture breakdown from the root.
-Life comparison: The cold shrink life exceeds 30 years, while the heat shrink life is only 4-6 years (reduced to 2-3 years in cold regions).
2. Heat shrink tubing
-Material limitations: Polyolefin plastic+a small amount of silicone rubber, which hardens and loses elasticity after heating.
-Fatal flaw: Unable to follow cable shrinkage, resulting in gaps at the interface after repeated thermal cycling, leading to insulation failure.
2、 Installation Revolution: Safe and Efficient vs. Complicated Risks
Dimension | Cold shrink tubing | Heat shrink tubing |
Tool requirements | Manual operation, complete by removing the support frame | Need to heat with a spray gun/hot air gun to 200 ℃ for shrinkage |
Installation time | Single point sealing to be completed within 3 minutes | Uniform heating is required, which may lead to incomplete shrinkage due to uneven operation |
Safety | Zero open flame, suitable for explosion-proof scenarios such as oil fields and chemicals | Hot work permit required for open flame operations, high fire risk |
> Minrong case: The installation efficiency of EPDM cold shrink tubing on offshore wind power platforms with salt spray is increased by 4 times, and insulation glue pollution is eliminated.
3、 Extreme environmental adaptability: full scene coverage vs. restricted conditions
-Cold shrink tubing:
-Temperature resistance range: -55 ℃~150 ℃ (silicone rubber)/-40 ℃~150 ℃ (EPDM), stable operation of Arctic Circle cables and desert photovoltaic fields.
-Anti aging: the performance is not damaged under salt spray, acid rain and ozone environment, and it has also passed the 2000 hour ultraviolet aging test (ASTM G53).
-Mechanical protection: Radial contraction force ≥ 48.6N/mm, wear-resistant and puncture resistant, directly buried cable resistant to gravel compression.
-Heat shrink tubing:
-Low temperature embrittlement (easy to crack below -30 ℃), high temperature softening (easy to drip flow above 125 ℃).
-After long-term outdoor use, the surface becomes powdery and the sealing performance deteriorates.
4、 Application scenario differentiation: outbreak of new energy vs. adherence to traditional fields
1. Leading areas of cold shrinkage:
-High voltage power grid: 10kV~35kV cable Terminals (such as Shanghai ± 550kV offshore wind power project).
-Dynamic environment: Railway contact network, ship swing cable (EPDM anti fatigue characteristics ensure sealing).
-Zero maintenance scenario: underground pipe gallery, underwater cable (30 years maintenance free).
2. Advantages of residual heat shrinkage:
-New energy vehicles: V0 level flame-retardant heat shrink tubing is used for battery pack wiring harness (resistant to rapid shrinkage at 120 ℃).
-Low cost scenario: Indoor low-voltage harness protection (300V level).
5、 Whole life cycle cost: Long term economy vs. short-term affordability
Cost item | Cold shrink tubing | Heat shrink tubing |
Unit price | High (cost of silicone rubber raw material ≈ 2 times heat shrink) | Low (polyolefin material is cheap) |
Installation cost | Save on heat source equipment and professional training costs | Require gas tanks/electric heating tools and certified personnel |
Maintenance cost | Approaching zero (30 years without replacement) | 5-year cycle replacement+downtime loss due to malfunction |
Comprehensive TCO | ↓ Decreased by 40% (10-year cycle calculation) | ↑ Increased (implicit maintenance costs account for over 60%) |
Conclusion: Disruption is a foregone conclusion, scene definition and selection
Cold shrink tubing, with its elastic memory, zero flame installation, and all climate tolerance, has reshaped industry standards, especially in high-voltage power, dynamic environments, and long-term scenarios, with overwhelming advantages. And heat shrink technology only retains cost advantages in low-pressure static environments (such as automotive wiring harnesses). With the breakthrough of intelligent cold shrinkage and environmentally friendly materials, the technological gap will continue to expand.
> Decision guide:
> Choose cold shrinkage: power grid infrastructure, new energy power stations, explosion-proof sites, high maintenance cost scenarios.
> Select heat shrink: Indoor wiring harnesses below 600V, short-term projects, cost sensitive applications.
